Ogee-Crested Weir With Pressure Measurement Manufacturer,Supplier and Exporter in Ambala
Product Code : EL-EFFCA-11065
Lab Equipments Ambala is a leading Ogee-Crested Weir With Pressure Measurement Manufacturer,and suppliers in Africa, Ogee-Crested Weir With Pressure Measurement Manufacturer,and suppliers in Nigeria,Ogee-Crested Weir With Pressure Measurement Suppliers in Ethiopia,Ogee-Crested Weir With Pressure Measurement in Supplier Kenya, Egypt, South Africa, Tanzania,Algeria, Uganda, Sudan, Morocco, Ghana, Mozambique, Ivory Coast, Madagascar, Angola, Cameroon, Niger, Burkina Faso, Mali, Malawi, Zambia, Senegal, Zimbabwe, Chad, Guinea, Tunisia, Rwanda, South Sudan, Benin, Somalia, Burundi, Togo, Libya, Sierra Leone
EXPERIMENTATION
Hydrodynamic overfall at the ogee-crested weir
Pressure distribution along the downstream side of the weir for different discharges
Nappe separation
Determination of discharge and head
Comparison of the theoretical and the measured discharge
Description :-
Ogee-crested weirs are fixed weirs and form part of the control structures.
They are often used to dam a river.
The weir itself consists of a massive damming body.
The outer weir contours roughly correspond to a triangle.
The downstream side of the weir is often designed to improve flow, in order to achieve the largest possible discharge.
The pressure distribution along the downstream side of the weir is studied.
The pressure measurement is realized via bores perpendicular to the surface of the downstream side of the weir.
The heads are directly indicated on the integrated manometer tubes.
TECHNICAL DETAILS
Manometer tubes
Measuring range : 290mmwc
Weir with chute LxWxH : 172x84x160 mm
Weir with chute with ski jump LxWxH : 210x84x160 mm
Total weight : approx. 4kg
SPECIFICATION
Ogee-crested weir for the experimental flume
Weir crest with chute with ski jump
Weir crest with chute
Weir body made of PVC
Weir body with sealing lips
