Vacuum Extractor Bird Anterior and Posterior Cups Set Manufacturer,Supplier and Exporter in India
Product Code : EL-HE-10948
Description:
Vacuum extractor, Bird with anterior and posterior cups, manual, complete set
Technical Specifications:
Vacuum extractor system to assist vaginal deliveries in a delivery room setting
Electrically powered vacuum/suction pump creates and maintains required vacuum
Suction flow maximum: approx. 30L/min
Front panel informs actual vacuum created, with dial gauge in kPa and mmHg
Vacuum range, adjustable: from 0 to approx. -90 kPa/ -675 mmHg
Gauge dial, minimal graduation: 5kPa/37.5 mmHg
Accuracy vacuum gauge: approx. 2.5 %
Servo system monitors vacuum, and when necessary initiates suction to compensate for loss of vacuum
With vacuum control button and on/off-switch
With foot pedal with operate/stop switch
All parts of the vacuum extractor can be disassembled, relevant parts can be autoclaved at 121°C
Plastic (PSU, autoclavable) vacuum/collection bottle, with filter keeps circuitry clean
Device has sturdy shock resistant and electrically isolated housing, easy to move and easy clean
Requires routine maintenance, manageable at the level of the delivery rooms
Power requirements: 220V/50Hz
Power consumption: 50W
System is supplied as a complete set, including:
2x Extraction handle for Bird type anterior suction/extraction cup
Suction/extraction cups and handle: stainless steel, Chrome/Nickl
.2X Bird type anterior suction/extraction cup (1x50 and 1x 60mm opening diameter) rounded edges
1X Bird type posterior suction/extraction cup (1x 50mm opening diameter) rounded edges
plated
1x Vacuum/collection bottle +lid, PSU, with clamp holder
1x Foot pedal with operate/stop switch
2x Soft suction/extraction cup (1x50 and 1x60mm opening diameter)
1x 5m Power cable, with wall plug, matching final destination of use (specified at the level of actual purchase orders)
1x Matching trolley, sturdy and stable construction on 4 antistatic swivel castors, all with brakes
Diameter castors: approx. 100mm
Material: PS coated metal
Carrying capacity: approx. 15kg
Back cable holder to facilitate transport and positioning
Trolley with standard rail for the attachment of vacuum/collection bottle, accessories and foot vacuum regulator
Overall dimensions:510mm x470mm x985 mm (lx w x h)
20x Polypropylene bottom plate, for stainless steel suction/extraction cup, 10 for each size, 50 and 60mm
1x List of accessories and parts
1x Spare vacuum/collection bottle
1x Spare tube,3m
1x Instructions for use and maintenance, and contact details for repair service, in English.
