Engineering Capacitive Load System 1.2 kVAR

Product Code : SCL-EAE-11169

The Engineering Capacitive Load System 1.2 kVAR is an electrical laboratory apparatus used to apply controlled capacitive reactive loading for AC circuit study, leading power factor demonstration, reactive power observation, and electrical machine training. It is suitable for engineering colleges, polytechnics, ITI/TVET centres, electrical training labs, distributors, and institutional procurement buyers.

Product Description

The Engineering Capacitive Load System 1.2 kVAR from Lab Equipments Ambala is best positioned under Physics Lab / Electrical and Electronics / Electrical Machine Training Apparatus. A dedicated product page with final product code, voltage rating, phase type, current rating, capacitance steps, switching arrangement, enclosure, protection, and duty cycle should be confirmed before publishing.

A capacitive load system provides reactive AC loading through capacitor sections. In laboratory use, a 1.2 kVAR capacitive load system helps students observe leading power factor, reactive current, phase relationship, voltage-current behaviour, and power-factor correction principles when used with approved AC sources and suitable measuring instruments.

Key Features

• 1.2 kVAR capacitive rating: product name indicates 1.2 kVAR reactive-load capacity; final duty rating should be confirmed.
• Capacitive load operation: supports AC experiments where current leads voltage due to capacitance.
• Power factor training: useful for demonstrating leading power factor and reactive power behaviour.
• Electrical machine use: suitable for alternator, transformer, and AC source experiments when correctly rated.
• Step or bank-based loading: may include switched capacitor sections; confirm final configuration before publishing.
• Measurement-compatible setup: can be used with voltmeters, ammeters, wattmeters, power factor meters, and power analyzers.
• Specifications pending: voltage, phase, current, capacitance steps, protection, discharge system, and enclosure details must be verified.

Technical Specifications

What's Included in the Kit

• Engineering Capacitive Load System 1.2 kVAR main unit
• Capacitor bank or capacitive load sections
• Step selector, switching panel, MCBs, or control switches
• Input/output terminals and earthing point
• Discharge resistor, protection fuse, indicator, or enclosure guard
• Instruction manual, wiring diagram, test report, calibration certificate, or documentation

Applications / Uses

• Applying 1.2 kVAR capacitive load to AC sources, alternators, and electrical machine trainers
• Studying leading power factor in AC electrical circuits
• Demonstrating phase relationship where current leads voltage in a capacitive circuit
• Observing reactive power, apparent power, real power, voltage, and current under load
• Supporting power-factor correction demonstrations when used with suitable inductive-load equipment
• Training students in safe capacitor-bank connection, switching, metering, discharge, and shutdown procedures

How to Use the Engineering Capacitive Load System 1.2 kVAR

1. Place the capacitive load system on a dry, stable, ventilated laboratory bench or floor stand.
2. Confirm voltage rating, phase type, current rating, 1.2 kVAR load rating, duty cycle, and earthing requirement before connection.
3. Connect the unit to the AC source, alternator, transformer, or trainer according to the approved wiring diagram.
4. Connect suitable instruments such as voltmeter, ammeter, wattmeter, power factor meter, or power analyzer.
5. Set the capacitor load control to the minimum or safest starting position before energising the circuit.
6. Switch on the supply and add capacitive load gradually using the approved switches or steps.
7. Record voltage, current, real power, apparent power, reactive power, power factor, and phase-lead observations.
8. Switch off the supply, discharge the capacitors according to the manual, and confirm safe voltage before disconnection or storage.

Safety note: Use the Engineering Capacitive Load System 1.2 kVAR only within its confirmed voltage, current, phase, kVAR, and duty ratings. Capacitors can retain charge after power is removed; use trained supervision, proper earthing, insulated leads, approved discharge procedure, protective switching, and verified zero-voltage checks before handling terminals.

Care & Maintenance

• Keep capacitor sections, terminals, switches, vents, and enclosure surfaces clean and dry.
• Inspect insulation, earthing continuity, terminal tightness, capacitor bulging, leakage, and overheating marks before operation.
• Do not exceed the confirmed kVAR rating, voltage rating, current rating, or duty cycle.
• Store the unit in a dry, dust-controlled area away from moisture, corrosive fumes, and mechanical impact.

Why Choose Lab Equipments Ambala

Lab Equipments Ambala manufactures and exports scientific laboratory instruments, lab experiment setups, science kits, mathematics kits, didactic models, and STEM models. The brand supplies electrical and electronics apparatus, physics laboratory equipment, lab meters, power supply units, component kits, and electrical practical training resources for educational institutions. Its equipment range supports hands-on learning in AC circuits, reactive loading, power factor, electrical machines, and power measurement. Buyers should request final specifications before procurement to confirm product code, voltage, phase, current rating, capacitance steps, discharge protection, packing, and documentation.
